17 Meter17 Meter Manlift for Rent in Abu Dhabi
An articulating boom lift, called a manlift or a boom loader in local usage, giving 17 metres of working height from a 1.8 x 0.8 m platform rated to 250 kg. The boom bends part-way along its length, so it can rise and then reach over an obstruction to put the basket where a straight boom cannot: over a canopy, past a plant room, or in behind pipework. Horizontal reach is 9.5 m, and like every boom lift the outreach available falls as the platform rises. Four-wheel drive lets it work off finished ground. It is also called a cherry picker.
Price on requestTell us the dates and the site and we will price it
Get Quote on WhatsAppClick above to get an instant quote from our team
Specifications
| Working Height | 17 m |
| Platform Capacity | 250 kg |
| Platform Size | 1.8 x 0.8 m |
| Horizontal Reach | 9.5 m |
| Power Source | Diesel |
| Drive | 4WD |
About the Boom Loader 17 Meter
The 17 metre manlift is the one to take when the 14 will not reach, and the reason is usually outreach rather than height. Horizontal reach is 9.5 metres against the smaller machine's 7.5, and that two-metre difference decides jobs where the base cannot be positioned close to the work: a landscaped frontage, a service road, a loading bay that has to stay clear. Working height is 17 metres, roughly five storeys. As on any boom lift the two headline figures are not simultaneously available. Outreach reduces as the platform rises, and the machine's chart governs what is possible at your particular combination. The platform is 1.8 by 0.8 metres and rated to 250 kg, slightly more than the 14 metre unit, which in practice means two people with a more substantial set of tools. It is diesel only, so this is an outdoor machine or one for a building that is not occupied. Four-wheel drive lets it travel across a site under its own power. The articulating boom does what the smaller machine does, going up, then over an obstruction, then back in to the working face, with more of everything to work with.
What it is good for
- Facade, cladding and glazing work up to about five storeys
- Reaching across an obstruction such as landscaping, a service road or a canopy, where the base cannot come close
- Steelwork inspection, bolting and finishing at height
- Signage, lighting and building services installation on larger elevations
- Work where the 14 m machine is on the chart but with no margin at your outreach
What it is not for
- Indoor and occupied buildings. Diesel only, so take the 14 m machine with its electric option
- Lifting materials. 250 kg covers people and tools, not loads
- Soft or sloping ground. It travels on four-wheel drive but must work from firm, level standing
What the site needs
Firm, reasonably level ground at the working position and along the route. Space to stand the base far enough back to use the full articulation. Overhead obstructions and power lines checked across the whole working envelope, and the ground verified where the machine will operate over a slab, basement or service run.
Common questions about the Boom Loader 17 Meter
What does the 17 m give me over the 14 m?+
Three metres of working height and two metres of outreach, 9.5 m against 7.5 m, plus a slightly larger platform at 250 kg rather than 230 kg. The outreach is usually the deciding factor. If the machine can be positioned right at the base of the work, the 14 m is often enough; if something is in the way, the extra reach is what you are paying for.
Can I use it inside a building?+
Not this one. It is diesel only, and diesel exhaust inside an occupied building is a ventilation problem that most sites will not accept. The 14 metre machine is available with an electric power source and is the right choice for indoor work.
How do I know it will reach my work position?+
Give us three measurements: the height you need to work at, the horizontal distance from where the machine can safely stand to the work, and what is in between. Outreach falls as the platform rises, so those numbers together determine whether it is on the chart. Guessing from the headline figures alone is how machines turn up and cannot reach.
What limits the platform to 250 kg?+
Stability. A boom lift is a cantilever, and everything in the basket acts at the end of it. The 250 kg includes the occupants, their tools and any materials, and exceeding it risks the machine rather than just tripping an alarm. Two people with tools is the working assumption.
